Popis produktu

Hardware Specifications

________________________________________

CPU

Quad-core, 2.00 GHz

RAM/FLASH

1 GB/512 MB

Ethernet ports

WAN: 1 x 100/1000/2500 Mbps

LAN: 1 x 100/1000/2500 Mbps

4 x 100/1000 Mbps

Wireless Specifications

________________________________________

Standard

IEEE802.11 ax/ac/n/g/b/a

MIMO

MU-MIMO

Wireless speed

2.4 GHz: 1150 Mbps

5 GHz: 4800 Mbps

Frequency band

2.4 GHz:

USA (FCC): 2.412 to 2.462 GHz

Europe (ETSI): 2.412 to 2.472 GHz

5 GHz:

USA (FCC): 5.15 to 5.35 GHz; 5.470 to 5.850 GHz

European (ETSI): 5.15 to 5.35 GHz; 5.470 to 5.725 GHz

Bandwidth

20-, 40- ,80-, and, 160-MHz

Conducted typical transmit output power*1

US (2.4GHz/5GHz):

29/29 dBm

EU (2.4GHz/5GHz):

20/29 dBm

Wireless security

Open, WPA2-PSK, WPA3-Personal

SSID number

8

Fast roaming

802.11r/k/v

MESH Networking

Smart Mesh

Antenna type

4 (internal)

Antenna gain

2.4Ghz: 3.65 dBi, 4x4: 4SS

5Ghz: 4.63 dBi, 4x4: 4SS

System Capacity & Performance*2

________________________________________

SPI firewall throughput LAN to WAN (Mbps)*3

2,000

Throughput with Application management on (Mbps)

2,000

Throughput with Threat management on (Mbps)

2,000

VPN Throughput (Mbps)*4

300

Max. TCP concurrent sessions*5

20,000

Max. gateway-to-gateway IPsec VPN tunnels

3

Max. remote VPN tunnels

5

VLAN interface

4

Security Features

________________________________________

Ransomware / malware prevention

Yes

Intrusion blocker

Yes

Dark Web Blocker

Yes

Stop mail fraud & phishing

Yes

Block Ads

Yes

Block VPN proxy

Yes

Firewall

Yes

Country Restriction (Geo IP blocking)

Yes

Exception list

Yes

Custom allowed / blocked domain

Yes

Traffic Management (applications & clients)

Yes

Security event analytics

Nebula Threat Report

Real-time threat intelligence*6

Yes

Web Filtering (Content Filter)*6

Yes

VPN Features

________________________________________

Site2site VPN

IPSec

Remote access VPN

Yes

Networking Features

________________________________________

WAN Type

DHCP/Static IP/PPPoE

Reserve IP (static DHCP)

Yes

Block clients

Yes

NAT - Virtual server

Yes

DHCP server and DHCP relay

Yes

Dynamic DNS (DDNS)

Yes

Static route

Yes

Guest Network

Yes

VLAN Segmentation

Yes

Management

________________________________________

Onboarding WAN setting method

Yes

Site-wide SSID management

Yes

Multi-site management

Yes

Client report

Yes

Remote support and diagnostics

Yes

Keep device settings in the Nebula

Yes

Live tools

Yes

Event Log

Yes

Nebula Pro Pack - Advance feature set*6

Yes

Power Requirements

________________________________________

Power input

12 V DC, 3.0 A

Max. power consumption (Watt Max.)

31W

Physical Specifications

________________________________________

Item

Dimensions (WxDxH)(mm/in.)

161.7 x 65 x 229 mm (6.37” x 2.56” x 9.02”)

Weight (g/lb.)

707/1.56

Environmental Specifications

________________________________________

Operating

Temperature

0°C to 40°C (32°F to 104°F)

Humidity

5% to 95% (Non-condensing)

Storage

Temperature

-30°C to 70°C (-22°F to 158°F)

Humidity

5% to 95% (Non-condensing)

Certifications

________________________________________

CE

Yes

FCC

Yes

BSMI

Yes
